HeartFelt® Linear Ceiling Panels combine the warmth and texture of polyester felt with crisp, visual lines, creating aesthetically and acoustically pleasing spaces.



Key Features

  • Very high acoustical performance up to .70 NRC
  • Modular, interior ceiling system with felt panels and square-edge design
  • Designed for easy plenum access
  • Three standard carrier modules vary reveal for acoustics and aesthetics
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • GREENGUARD Gold Certified
  • Cradle to Cradle Certified™ Bronze

Dimensions/Colors & Finishes:

  • Panel dimensions: 1 9/16" x 2 3/16" (40 mm x 55 mm)
  • Panel length: 8'
  • Available in a variety of grey and earth tone colors – Crème, Umber, and Middle Grey – to name a few.

Physical Data

  • Substrate: Non-woven PES fibers (felt)
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: US - Class A Fire Rated per ASTM E84
    • Flame spread: ≤ 25, Smoke ≤ 300
  • Fire rating: Canada - per CAN/ULC S102.2-10
    • Flame spread: = 5, Smoke = 90
  • Weight: Varies
  • Wind load: N/A
  • Recycled content: Up to 85%



Learn more at: https://www.certainteed.com/ceilings-and-walls/felt/products/heartfelt/
